System Setup
System Setup features a set of functions allowing user to do perform maintenance on the
fixture.
To enter the System Setup page, first turn off the fixture, then press and hold the control dial
while turning the fixture back on. Keep on holding the control dial until the system setup page
is shown on OLED monitor.
There are 7 functions in the System Setup screen.
1. Firmware
2. Restore
3. Reset
4. Test Mode
5. Model Number
6. Standard or Master/Slave mode
7. Exit
1. Firmware
This function allows the user to update the firmware.
Rotate the control dial to select “Firmware”.
Press the control dial to begin the firmware update.
When there is no TF (micro SD) card or invalid firmware
in the TF card, “NO TF Card” or “Wrong File” will be
shown.
Otherwise the firmware update progress will be shown.
Once the firmware has been updated successfully, the
fixture will restart automatically and the new firmware
version number will be shown.
