13
Maintenance Instructions
6. Standard or Master/Slave Mode
This function allows the user to choose between the Standard stand-alone operation mode,
or Master/Slave mode where multiple units of RSX fixtures can be connected together.
Once connected, all Slave fixtures will follow the settings programmed on the Master fixture,
saving time and effort on setting up multiple fixtures.
The default value is Standard meaning the fixture is running in stand-alone operation mode.
When a RSX is set as Master Unit, it will need to assign a channel from 01 to 10. All connecting
Slave Units must be also assigned to the same channel.
In case where multiple groups of Master/Slave coexist in a proximity, each Master Unit must
assign a different channel to avoid interference with another group.
Rotate the control dial to select “Standard”.
Press the control dial to enter the setting page.
Rotate the control dial to assign it as a “Master” or
“Slave” unit.
After selecting Master/Slave unit, press the control dial to
assign a channel.
Press and hold the control dial for 3s to save the setting.
7. Exit
Press “Exit” to restart the fixture.
English
