MAXTHERMO MC-2838 - Alarm Selection Table

To Next Page

To Previous Page

Code Description Inhibit

00 None or master & solver function use. -

10 Deviation high limit alarm -

01 Deviation high limit alarm YES

11 Deviation high limit alarm NO

02 Deviation low limit alarm YES

12 Deviation low limit alarm NO

03 Deviation high / low limit alarm YES

13 Deviation high / low limit alarm NO

04 / 14 Dand alarm NO

05 Absolute value high limit alarm YES

15 Absolute value high limit alarm NO

06 Absolute value low limit alarm YES

16 Absolute value low limit alarm NO

07 Segment end alarm (use for program model only ) -

17 Segment run alarm (use for program model only ) -

08 System error alarm-(on) -

18 System error alarm-(off) or loop broken alarm -

09 Ramp -

19 Soak (On delay timer alarm) -

Alarm selection table:

P.12
