MAXTHERMO MC-2838 - Alarm Action Descriptions; Alarm Code Action Details

: SV
: Alarm set value
(Inhibit means alarm doesn’t work at first time)
00
10
Non
01
Deviation high alarm inhibit
11
Deviation high alarm no inhibit
02
Deviation low alarm inhibit
12
Deviation low alarm no inhibit
03
High low alarm inhibit
13
High low alarm no inhibit
04
14
Band alarm
05
Absolute high alarm inhibit
15
Absolute high alarm no inhibit
OFF
LOW HIGH
ON
OFF
LOW HIGH
ON
OFF
LOW HIGH
ON
OFF
LOW HIGH
ON
OFF
LOW HIGH
ON ON
OFF
LOW HIGH
ON ON
LOW HIGH
ONOFF
OFF
LOW
HIGH
OFF ON
LOW
HIGH
OFF ON
LOW
HIGH
OFFON
06
Absolute low alarm inhibit
16
Absolute low alarm no inhibit
07
Segment end alarm
(use for Program Model only)
(1) ALD1~3, set 07
(2) AL1~3 = alarm segment No.set
(3) ALT1~3 if set 0 = flicker alarm
ALT1~3 if set 99.59 = continued alarm
ALT1~3 if set others = ON delay time
17
Program Run alarm (Refer to SETA4, P.23)
(use for Program Model only)
08
System error alarm – ON
18
System error alarm - OFF
09 Ramp
19
On delay timer
When PV= alarm SV , it keeps a certain
period (set time) before alarm action
Range:00H00M~99H59M
LOW
HIGH
OFFON
RUN END
ON OFF
AL
Normal
Error
ONOFF
AL
RUN END
ON OFF
AL
Alarm action description:
Alarm action description:
