Maxtor D540X-4K - Chapter 3 INSTALLATION; 3.1 SPACE REQUIREMENTS

Maxtor D540X-4K 20.4/40.0/60.0/80.0 GB AT 3-1
%

This chapter explains how to unpack, configure, mount, and connect the Maxtor
D540X-4K 20.4/40.0/60.0/80.0 GB AT hard disk drive prior to operation. It also
explains how to start up and operate the drive.
! 2
The Maxtor D540X-4K hard disk drives are shipped without a faceplate. Figure 3-
1 shows the external dimensions of the Maxtor D540X-4K 20.4/40.0/60.0/80.0
GB AT drives.
 Mechanical Dimensions of Maxtor D540X-4K Hard Disk Drive
