Installation
3-4 Maxtor D540X-4K 20.4/40.0/60.0/80.0 GB AT
! %
The configuration of a Maxtor D540X-4K 20.4/40.0/60.0/80.0 GB AT hard disk
drive depends on the host system in which it is to be installed. This section describes
the hardware options that you must take into account prior to installation. Figure 3-
4 shows the printed circuit board (PCB) assembly, indicating the jumpers that
control some of these options.
#
Jumper Locations for the Maxtor D540X-4K Hard Disk Drive
$
Jumper Locations on the Interface Connector
