10
Chapter 3: Locations
Exterior Views
Hull Views
TRANSOM
BOARDING
LADDER
STERN
EYE
STERN
EYE
GARBOARD
DRAIN PLUG
STARBOARD HULLSIDE
PORT HULLSIDE
BILGE PUMP
DRAIN
TRANSOM STORAGE
DRAIN
ANCHOR LOCKER
DRAIN (2400SC ONLY)
BOW EYE
STERN
EYE
TRANSOM STORAGE
DRAIN
SINK DRAIN
(2400SR ONLY)
GALLEY SINK DRAIN
(2400SC ONLY)
