Maxum 2400SR - 2400 SC Deck Layout

Chapter 3: Locations
11
2400SC Deck Views
CLEAT
PORT GRAB
RAIL
PORT BOW
LIGHT
CLEAT
ANCHOR
LOCKER
BOW
HATCH
ANCHOR
ROLLER
STARBOARD
BOW LIGHT
CLEATHORNSTARBOARD
GRAB RAIL
CLEAT
WATER TANK
VENT
WATER FILL
DECK FITTING
ALL AROUND LIGHT
CLEAT
CLEAT
FUEL FILL
DECK FITTING
FUEL TANK
VENT
TRANSOM
SHOWER
BOARDING
LADDER
GRAB
HANDLE
TRANSOM
STORAGE
PORTABLE TOILET
PUMP-OUT DECK FITTING
(IF EQUIPPED)
PORTABLE TOILET
WASTE VENT
(IF EQUIPPED)
ENGINE VENT
(TYPICAL PORT
& STARBOARD)
SKI TOW
RING
