Chapter 3: Locations
14
Fuel Tank: In the engine compartment, forward of the engine (refer to page 13 for location view).
Navigation Lights: Red and green lights at the bow (refer to pages 9 & 10 for location views). White all-around light
on the stern (refer to pages 9 & 10 for location views).
Portable Toilet Pump-out Deck Fitting (If Equipped):
• 2400SR: On the port side deck (refer to page 9 for location view).
• 2400SC: On the starboard side deck (refer to page 10 for location view).
Water Fill Deck Fitting: On the starboard side deck (refer to pages 9 & 10 for location views).
Water Pump Switch:
• 2400SR: On the aft wall in the starboard
storage compartment.
• 2400SC: In the head compartment, on the aft wall.
Water Tank: Access is through the deck plate inside the
ski locker.
WATER PUMP
SWITCH
FORWARD
WATER PUMP
SWITCH
FORWARD
SKI LOCKER HATCH
