Maxx Cold SELECT MXSF-23FD User Manual

Page 7 of 58
DIMENSIONS
The overall height of the unit may be reduced by over 2” with an optional shorter caster set of 4 heavy duty casters (2 come with
brakes).
TECHNICAL INFORMATION
Model MXSF-23FD MXSF-49FD
In: Overall Dimension W*D*H 27 x 33.3 x 83.5 54.1 x 33.3 x 83.5
mm: Overall Dimension W*D*H 686 x 846 x 2121 1374 x 846 x 2121
Nominal Capacity 19.3 Cu Ft / 547 L 42.9 Cu Ft / 1215 L
Unit Weight 280 lbs / 127 kg 470 lbs / 213 kg
Hinged Doors 1 2
Shelves 3 6
Electrical Service 110V/60Hz/1Ph 110V/60Hz/1Ph
Wattage 320 W 520 W
Average Amp Draw 1.5 3.7
Refrigerant R-404A R-404A
Provided 6’ NEMA Cord Set 5-15 5-15
Factory Temperature Setting 5°F (-15°C) 5°F (-15°C)
MXSF-49FD
MXSF-23FD
27 in
686 mm
33.3 in
846 mm
27 in
686 mm
60.5 in
1537 mm
Max Door Swing
Clearance
60.5 in
1537 mm
Max Door Swing
Clearance
27 in
686 mm
33.3 in
846 mm
54.1 in
1374 mm
27 in
686 mm
33.3 in
846 mm
33.3 in
845.8 mm
54.1 in
1374 mm
83.5 in
2121 mm
83.5 in
2121 mm
78.5 in
1994 mm
78.5 in
1994 mm
5 in
127 mm
5 in
127 mm
