WIRING DIAGRAMS
MODEL
：
ALL MODELS
PARTS
Item # Part Number Descriptions Qty / Unit
1 DOOR GASKET-1 Gasket 1
2 DOOR GASKET-2 Gasket 1
3 DOOR GASKET-3 Gasket 1
4 DOOR GASKET-4 Gasket 1
5 DOOR GASKET-5 Gasket 2
6 DOOR GASKET-6 Gasket 2
MXSH15.9S
MXSH12.7S
MXSH9.6S
1
2
3
MXSH19.4S MXSH23.6S
MXSH30.0S
4 5 6
L
E
N
G
COMPRESSOR
ON LIGHT
POWER
LIGHT
CAPACITOR
PTC STARTER
MOTOR
PROTECTOR
COMPRESSOR
THERMOSTAT
G
G
PLUG
