Maxx Cold Select Series User Manual

Page 6 of 16
DIMENSIONS
TECHNICAL INFORMATION
Model MXSH9.6S MXSH12.7S MXSH15.9S
In: Overall Dimension W*D*H 40.6 x 29.7 x 33.625 50 x 29.7 x 33.625 60.2 x 29.7 x 33.625
mm: Overall Dimension W*D*H 1030 x 755 x 854 1270 x 755 x 854 1530 x 755 x 854
Nominal Capacity 9.6 Cu Ft / 272 L 12.7 Cu Ft / 360 L 15.9 Cu Ft / 450 L
Appliance Weight 119 lbs / 54 kg 132 lbs / 60 kg 165 lbs / 75 kg
Hinged Lids 1 1 1
Storage Basket 1 1 2
Electrical Service 115V/60Hz/1Ph 115V/60Hz/1Ph 115V/60Hz/1Ph
Average Amp Draw (WATTS) 0.6 (105) 0.8 (125) 0.85 (145)
Temperature Range Fº/Cº
0º to 11º F
-24º to -18º C
0º to 11º F
-24º to -18º C
0º to 11º F
-24º to -18º C
Refrigerant R-134A R-134A R-134A
Provided 6’ NEMA Cord Set 5-15 5-15 5-15
Factory Temperature Setting 5°F (-15°C) 5°F (-15°C) 5°F (-15°C)

Maxx Cold Select Series Specifications

General

Brand	Maxx Cold
Model	Select Series
Category	Freezer
Language	English
