Maxx Cold Select Series User Manual

Page 7 of 16
DIMENSIONS
TECHNICAL INFORMATION
Model MXSH19.4S MXSH23.6S MXSH30.0S
In: Overall Dimension W*D*H 71.3 x 29.7 x 33.625 78.75 x 29.7 x 33.625 76 x 35.25 x 35.83
mm: Overall Dimension W*D*H 1810 x 755 x 854 2000 x 755 x 854 1930 x 895 x 910
Nominal Capacity 19.4 Cu Ft / 549 L 23.6 Cu Ft / 669 L 30 Cu Ft / 850 L
Appliance Weight 181 lbs / 82 kg 176 lbs / 80 kg 209 lbs / 95 kg
Hinged Lids 1 2 2
Storage Basket 2 2 2
Electrical Service 115V/60Hz/1Ph 115V/60Hz/1Ph 115V/60Hz/1Ph
Average Amp Draw (WATTS) 1.0 (160) 2.0 (200) 2.2 (220)
Temperature Range Fº/Cº
0º to 11º F
-24º to -18º C
0º to 11º F
-24º to -18º C
0º to 11º F
-24º to -18º C
Refrigerant R-134A R-134A R-134A
Provided 6’ NEMA Cord Set 5-15 5-15 5-15
Factory Temperature Setting 5°F (-15°C) 5°F (-15°C) 5°F (-15°C)
