Step 2: MAXX OLYMPIC Rack
Install Bumper Plate(4), Bar Holder Φ48*2.5*280(5), End Cap Φ8.5*Φ47.5*30(6), Rubber Bushing
Φ75*Φ26*Φ48.5*25(8) to Upright Frame (1&2) using Flat Washer Φ13.5*Φ24*2.5(14), Spring Washer Φ12(15), Hex
Bolt M12*30(17) and Hex Bolt M8*25(19) as show.
page 10
