February, 2019 eMAX-LP1502-Man Page 12 of 20
12. Status LEDs:
Power-up: All LED's OFF.
Initialization: After power is applied or reset switch pushed, LED 1 is ON for about 15 seconds, then
LED’s 2, 3, 4, 5, 6, R1, R2, IN1, IN2, IN3, IN4, IN5, IN6, IN7 and IN8 are flashed once at the beginning
of initialization. LEDs 3 and 4 is turned ON for approximately 1 second after the hardware initialization
has completed, then the application code is initialized. The amount of time the application takes to
initialize depends on the size of the database, about 1 second without a card database. Each 10,000
cards will add about 2 seconds to the application initialization. When LED's 1, 2, 3 and 4 flash at the
same time, data is being read from or written to flash memory, do not cycle power when in this state.
If the sequence stops or repeats, perform the bulk erase procedure, see section 4.
Running: After initialization is complete, the LEDs have the following meanings:
Off-Line / On-Line and Battery Status
Off-Line = 20% ON, On-Line = 80% ON
Double Flash if Battery is Low
Host Communication Activity (Ethernet or Micro USB port)
Internal SIO Communication Activity
External SIO Communication Activity
Reader 1:
Clock/Data or D1/D0 Mode: Flashes when Data is Received, Either Input
F/2F Mode: Flashes when Data/Acknowledgment is Received
RS-485 Mode: Flashes when Transmitting Data
Reader 2:
Clock/Data or D1/D0 Mode: Flashes when Data is Received, Either Input
F/2F Mode: Flashes when Data/Acknowledgment is Received
RS-485 Mode = Flashes when Transmitting Data
Flashes with Ethernet Traffic
Ethernet Speed: OFF = 10Mb/S, ON = 100Mb/S
OFF = No Link, ON = Good Link, Flashing = Ethernet Activity
Input IN1 Status: OFF = Inactive, ON = Active, Flash = Fault. See Note 3.
Input IN2 Status: OFF = Inactive, ON = Active, Flash = Fault. See Note 3.
Input IN3 Status: OFF = Inactive, ON = Active, Flash = Fault. See Note 3.
Input IN4 Status: OFF = Inactive, ON = Active, Flash = Fault. See Note 3.
Input IN5 Status: OFF = Inactive, ON = Active, Flash = Fault. See Note 3.
Input IN6 Status: OFF = Inactive, ON = Active, Flash = Fault. See Note 3.
Input IN7 Status: OFF = Inactive, ON = Active, Flash = Fault. See Note 3.
Input IN8 Status: OFF = Inactive, ON = Active, Flash = Fault. See Note 3.
Note: If this input is defined, every three seconds the LED is pulsed to its opposite state for 0.1
seconds, otherwise, the LED is off.
