DIP Switches:
The four switches on S1 DIP switch configure the operating mode of the eMAX-LP1502 processor.
DIP switches are read on power-up except where noted.
1
2
3
4
Definitions
OFF
OFF
OFF
OFF
Normal operating mode.
ON
X
OFF
OFF
After initialization, enable default User Name (admin) and
Password (password). The switch is read on the fly, no need to re-
boot. See IT Security section for additional information.
OFF
ON
OFF
OFF
Use factory default communication parameters.
ON
ON
OFF
OFF
Use OEM default communication parameters. Contact system
manufacture for details. See Bulk Erase section below.
ON
ON
OFF
OFF
Bulk Erase prompt mode at power up. See Bulk Erase below.
X
X
X
ON
Makes the LP1502 report and function like an EP1502. To be used
in situations where the host software has not been updated to
support the LP series product line.
All other switch settings are unassigned and reserved for future use. (X = don’t care)
Factory Default Communication Parameters:
Interface 1 (NIC1)
Network: static IP address: 192.168.6.12
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.6.1
DNS Server: 192.168.6.1
Primary Host port: IP server, Data Security: TLS if Available, port 3001, communication address: 0
Alternate Host Port: Disabled
(Refer to online HELP in the Maxxess host software for important details on encryption)
NOTE: See Appendix A for details on configuring the eMAX-LP controller’s IP address
4. Bulk Erase Configuration Memory:
The bulk erase function can be used for the following purposes:
➢ Erase all configuration and cardholder database (sanitize board)
➢ Update OEM default parameters after OEM code has been changed
➢ Recover from database corruption causing eMAX-LP1502 board to continuously reboot
If clearing the memory does not correct the initialization problem, contact technical support.
Bulk Erase Steps: Do not remove power during steps 1-8.
1. Set S1 DIP switches to: 1 & 2 "ON", 3 & 4 "OFF".
2. Apply power to the eMAX-LP1502 board. LED 1 on for up to 15 seconds while board boots up.
3. After the eMAX-LP1502 boots up, watch for LEDs 1 & 2 and 3 & 4 to alternately flash at a 0.5
second rate.
4. Within 10 seconds after the above pattern starts, change switches 1 or 2 to "OFF". If these
switches are not changed, the eMAX-LP1502 board will power up using the OEM default
communication parameters.
5. LED 2 will flash indicating that the configuration memory is being erased.
6. Full memory erase takes up to 60 seconds, usually a lot less.
7. When complete, only LEDs 1 & 4 will flash for about 3 seconds.
8. The eMAX-LP1502 will complete its initialization in 2 seconds after LEDs 1 & 4 stop flashing.
