Maxxus 8.1 User Manual

Parts List
25
Part
Description
Size
Qty
93
Wire to controller
1
94
Inner hex full thread screw
M8*15
4
95
Screw
M8*65
1
96
Fan
1
97
Tube plug
Ø19.5xØ14.2x8.5
2
98
Decorate rail
2
99
Wire clip
1
100
Spring cushion
Ø8
2
101
Cross Allen screw
M5x15
2
102
Computer Wire
1
103
Cross self-taping screw
ST4x12
14
104
Cross allen full head screw
M3x28
4
Parts - Cockpit
Part
Description
Size
Qty
47
Complete computer
1
47-1
Computer housing(up)
1
47-2
Computer housing(down)
1
47-3
Computer front cover
1
47-4
The swinging plate
1
47-5
air outlet left
1
47-6
air outlet right
1
47-7
Fan
1
47-8
Speaker
2
47-9
Safety key metal sheet
1
47-10
Safety key press part
1
47-11
Safety sensitive switch
1
47-12
Safety key sticker
1
47-13
Cross screw M4*40
M4x40
2
47-14
Console overlay
1
47-15
PCB board
1
47-16
PCB board for big buttons
1
47-17
PCB board for small buttons
1
47-18
Earphone socket(for option)
1
47-19
Safety key pull part
1
47-20
Spring
1
