14
7. Slide the Bench Heater Panel down (vertically) into the slot provided on both the
Left and Right Side panels. Connect the Bench Heater Panel cord with the outlet on
the Back Panel and then place the Bench on top of the Bench Heater Panel and
slide it into place. See FIG-9 & 10 Note: Make sure the cords are connected snug
and tight, otherwise the heater will not work.
FIG-9 Connecting Cord FIG-10 Installing Bench
8. Align the Front Panel with the Floor Panel’s corresponding patterns; make sure the
wood pattern is flowing in the same direction. Next, latch the Front Panel with the
Left and Right Side Panels respectively. Note: Be cautious with the glass door to
avoid breakage. See FIG-11.
FIG-11 Assembling Front Panel FIG-12 Installing Roof Cover
To Next Page
