Maxxus SmartGym H1 User Manual

53
53
22
22
22
29
29
22
6
Assembly
Step 4:
Fix the front cover using the washers (18) and screws M8x15 (41) to the front of the HomeGym H1.
Step 5:
Hook the 2 handles (29) onto the two brackets on the traction unit using the snap hooks (22).
If you need this to be longer, use the chains included in delivery (53 ). If necessar y, you can also use longer chains. You can
usually obtain suitable chains for this from any DIY or ha rdware store.

Maxxus SmartGym H1 Specifications

General

Brand	Maxxus
Model	SmartGym H1
Category	Fitness Equipment
Language	English
