Maytag CCG2420 - Wiring Information

Model/Serial Plate
The Model/Serial plate is located on the
bottom of the cooktop towards the back. For
downdraft models, the model/serial plate is
located on
the side of the plenum under the
cooktop. The model number is very
important to the technician for ordering parts
both in and
out of warranty. Always be sure
to use the complete model number when
ordering parts.
A IMPORTANT
UniqlJe product information for specific
models is found in the
wiring and model specific information
section of this manual.
16010242
Wiring Information
A wiring diagram / schematic is supplied
with the unit. It is attached to the underside
of the cooktop. Please return the diagram to
the storage compartment for future use.
A IMPORTANT
Wiring information in this manual was ac-
curate
at the time of manual production.
Wiring information is subject to change at
any time. Please refer to wiring informat-
ion on the actual product for most current
information.
