Maytag MAH8700A - Wiring Schematics

Wiring Schematics
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testing requires power.
June 2006 13 16026882
©2006 Maytag Services RPL 16026127
NOTE: Series 10 – 11 do not have connector CN11 or MEMS PCB originally.
Series 12
