Component Testing Procedures
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testing requires power.
16022846 Rev 0 December 2003
14
Washer stuck
with 0 minutes
remaining in
display
Lift washer lid. Did
display change?
The washer lid must be
opened after a program
ends before the washer
will operate again
Unplug washer
and check
continuity of lid
switch as lid is
raised and lowered
Does lid switch
open and close
properly? Is lid
switch wet?
Check wiring and
termination between lid
switch and control board
Plug in washer. If
problem still exists
replace control
board
Adjust lid switch or
replace it if
necessary
Control does not
respond to
program key
inputs
Does display show
"select cycle"?
Check touch pad in service
mode. Does control board
respond? Unplug washer
and check membrane switch
tail connection. Plug washer
back in .
Put proper number
of coins into coin
drop
If problem still
exist replace
control board
If problem still exist
replace membrane
switch
Yes
No
Yes
No
Yes
No
To Next Page
