Component Testing Procedures
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testing requires power.
16022846 Rev 0 December 2003
8
CODE DISPLAY EXPLANATION
h.01 h. SUPER CYCLE TYPE (Skipped unless super cycle pricing is selected “F.Su”.)
01
This represents the super cycle upgrade option. Press Permanent Press keypad to step through
upgrade option 1 through 3 as follows:
01-enhanced wash, extra 3 minutes of wash tumble in addition to programmed wash time.
02- extra rinse for all cycles, final warm rinse for WHITES, COLORS, and DELICATE & KNITS.
03- both 01 and 02.
Press Woolens keypad once to advance to the next code.
J.Cd J. COIN/DEBIT OPTION
Cd
C_
_d
Press Delicates & Knits keypad 3 consecutive times for this selection
Both coin and debit turned “ON”.
Coins selected, debit disabled.
Debit card selected and coins disabled.
Ed
Enhanced debit is self-selected when a Generations 2 card reader is installed in the washer. The
“Ed” option cannot be manually turned “ON” and “OFF”
Press Woolens keypad once to advance to the next code.
L.00 L. PRICE SUPRESSION OPTION
This option causes the customer display to show “ADD or “AVAILABLE” rather than the amount of
money to add (Used mainly in debit installation). Press Delicates & Knits once to turn “ON” or “OFF”.
00 “OFF”
PS
“ON”
Press Woolens keypad once to advance to the next code.
n.CE n. CLEAR ESCROW OPTION
When elected, money held in escrow for 30 minutes without further escrow or cycle activity will be
cleared. Press Delicates & Knits once to turn “ON” or “OFF”.
00 “OFF”
CE
“ON”
Press Woolens keypad once to advance to the next code.
U.00 U. PENNY INCREMENT OFFSET
00
This represents the penny increment price offset used un Generation 2 (enhanced Debit) PR
models. Choose from 0-4 pennies by pressing the Permanent Press keypad.
Press Woolens keypad once to advance to the next code.
WASHER DIAGNOSTIC CYCLE
The mode is entered by depressing Delicates & Knits keypad for one second while in any of the set-up modes one
through six or with a diagnostic code present. Diagnostic codes are cleared on entry and all display segments
should flash. If a diagnostic code persists, it must be corrected before the diagnostic cycle will start. With all
segments flashing, depressing the Woolens keypad starts the diagnostic cycle.
Display Function Time Length
C Cold Fill 3 seconds
H Hot Fill 3 seconds
CH Warm Fill 3 seconds
A Agitation 3 seconds
S Spin 9 Seconds
Note: 1) Woolens keypad can be used to pause/resume the diagnostic cycle.
2) Delicate & Knits keypad will cancel the cycle and exit the diagnostic mode.
3) Permanent Press keypad, “CC”(Free cycle) will be displayed. When you exit the service mode
“Select Cycle” will be displayed.
To Next Page
