Maytag MAT15MN - Remove Power Cord

4-12
Remove the control panel (see page 4-1).
Lift the locking tab and disconnect the
connector.
Rotate the power cord connector and pull it
out of the back of the feature panel.
1.
2.
3.
REMOVE THE POWER CORD
Power cord
connector
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
