Maytag MDB4949SDM User Manual

3
Parts and Features
BOTTOM RACK
TOP RACK
Upper level wash
Water feed tube
Model and serial number label
Water inlet opening
Detergent dispenser
Heating element
Upper spray arm
Silverware basket
(varies by model)
Cup shelf
(varies by model)
Overfill protection float
Lower spray arm has pressurized sprays
that provide effective cleaning.
Rinse aid dispenser reduces
spotting and improves drying.
Rack height adjusters
(on some models)
Fold down tines
(on some models)
High side shelf
(on some models)

Maytag MDB4949SDM Specifications

General

Style	built-in dishwashers
Color	monochromatic stainless steel, stainless steel
Cycle Selections	powerblast, auto, normal, quick, rinse
Options/Settings	heated dry, hi temp wash, sani rinse®, control lock, 1-24 hour delay
Delay Start	yes
Number of Racks	2
Cycle Signal	yes
Water Filter	yes
Food Disposer	yes
Sanitize Settings	no
Annual Energy Consumption	270 kilowatt hours
Voltage	120 volts
Current	15 amperes

Weight and Dimensions

Depth	25.2 inches
