Maytag MDB8600AWS - Pump & Motor

PUMP & MOTOR
No. Part No. Description
Section:
Series Qty
1 99002654 CAP, WASH ARM 10 1
2 99002678 WASH ARM, LOWER (W/SHIELDS) 10 1
3 99002653 SHIELD, RADIANT 10 2
- 99002666 SCREW Note: SCREW, GUARD 10 3
4 99002655 GUARD, FILTER (GRAY) 10 1
5 99002677 DISCHARGE HOUSING ASSY (UPR) 10 1
- 99002664 SCREW, DISCHARGE HOUSING 10 6
6 99002741 WASH IMPELLER ASSEMBLY 10 1
- 99002660 SCREW, IMPELLER 10 1
7 99002661 FILTER/FLOWPLATE ASSEMBLY 10 1
- 99002668 SCREW, STAINLESS PAN HEAD Note: SCREW, FILTER/FLOWPLATE 10 3
8 99002658 CHOPPER 10 1
9 99002981 WASH MOTOR SEAL KIT 20 1
9 99002760 WASH MOTOR SEAL KIT 10 1
10 99002759 WASH MOTOR ASSY SEAL NOT INCL Note: ORIG PART HAS SEAL. SUB PART WILL NOT HAVE
SEAL. ORDER SEAL SEPERATELY.
10 1
10 99002980 WASH MOTOR ASSY SEAL NOT INCL 20 1
- 99002651 O-RING, TURBIDITY SENSOR 10 1
11 99002650 SENSOR, TURBIDITY 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, SENSOR 10 2
12 99002663 GASKET, PUMP 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, CAPACITOR 10 1
13 99002665 CAPACITOR, MOTOR 10 1
14 99002750 DRAIN PUMP ASSEMBLY 10 1
- 99002815 FLAPPER, DRAIN PUMP VALVE 10 1
15 99003058 FLAPPER, DRAIN FILTER 10 1
16 99002857 O-RING, DRAIN PUMP 10 1
- 99002657 SCREW, DRAIN PUMP MOUNTING 10 1
17 99002752 BRKT, DRAIN PUMP (W/GROMMET) 10 1
- 99002656 CLAMP, DRAIN HOSE (1-3/8") 10 1
18 99002652 HOSE, DRAIN 10 1
15
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
