Maytag MDB8600AWS - Control Panel

CONTROL PANEL
No. Part No. Description
Section:
Series Qty
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, PANEL 10 4
1 99002787 PANEL, CONTROL (BLK) 10 1
2 99002573 VENT SEAL, CONTROL PANEL 10 1
3 99002577 HANDLE, LATCH (BLK) 10 1
4 99002751 SWITCH, DOOR 10 2
5 99002580 LATCH ASSEMBLY 10 1
6 99002576 HOUSING, BOARD (BASE) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 10 2
7 99002978 BOARD, CONTROL 19 1
7 99002844 BOARD, CONTROL 11 1
7 99002726 BOARD, CONTROL 10 1
8 99002575 HOUSING, BOARD (TOP) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 10 1
- 99002845 WIRE HARNESS, MICROPROCESSOR 11 1
- N 99002581 WIRE HARNESS, MICROPROCESSOR Note: (NEED TO ORDER CONTROL BOARD KIT 99002864) 10 1
- 99002986 WIRE HARNESS, MICROPROCESSOR 20 1
3
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
