Maytag MDB8600AWS - Page 19

RACK ASSEMBLY (MIDDLE/LWR)
No. Part No. Description
Section:
Series Qty
- 99002905 CAP, RACK (DARK GRAY) 10 1
1 99002727 RACK ASSEMBLY (MIDDLE) 10 1
1 99003207 RACK ASSEMBLY (MIDDLE) 23 1
2 99002853 SNUGGER, RACK 10 2
3 Y00000000 SEE NOTE Note: FOR RIGHT TINE ORDER FRONT TINE ASSY(PART 99003639) 10 1
4 Y00000000 SEE NOTE Note: FOR LEFT TINE ORDER FRONT TINE ASSY(PART 99003639) 10 1
5 99002737 LATCH, FOLD AWAY TINE (FRT) 10 1
6 99002735 PIVOT, FOLD AWAY TINE 10 2
7 99002621 TRACK, RACK 10 2
- 99002623 STOP, RACK (GRAY) 10 4
- 99002343 SHAFT, TUB WHEEL 10 8
8 99002622 WHEEL, TUB 10 8
- Y912798 WASHER, TUB WHEEL 10 8
- 99002740 SCREW, TRUSS HEAD (10-18X.75) Note: SCREW, WASH ARM 10 1
9 99002739 ARM, WASH (MIDDLE) 10 1
10 99002732 CLIP, MIDDLE MANIFOLD (FRT) 10 1
11 99002758 CLIP, MIDDLE MANIFOLD (BACK) 10 1
12 99002793 WASH MANIFOLD ASSY (MIDDLE) 10 1
13 99002735 PIVOT, FOLD AWAY TINE 10 2
14 Y00000000 SEE NOTE Note: FOR LEFT TINE ORDER REAR TINE ASSEMBLY (PART 99003640) 10 1
15 99002736 LATCH, FOLD AWAY TINE (REAR) 10 1
16 Y00000000 SEE NOTE Note: FOR RIGHT TINE ORDER REAR TINEASSEMBLY (PART 99003640) 10 1
- 99003020 STABILIZER, RACK ADJUSTER 23 1
- 99003178 LEVER, ADJUSTER (BLUE) 23 2
17 N 99002783 ADJUSTER, RACK (RT) Note: (MUST ORDER RACK ASSEMBLY) 10 1
- 99003010 SCREW (T15) 8-18 X .500 23 11
- N 99002782 ADJUSTER, RACK (LT) Note: (MUST ORDER RACK ASSEMBLY) 10 1
- 99003009 RACK ADJUSTER ASSEMBLY (RT) 23 1
- 99003008 RACK ADJUSTER ASSEMBLY (LT) 23 1
- 99003011 COVER, RACK ADJUSTER (GRAY) 23 2
- 99002730 BASKET, SPLIT/FIT 10 2
- 99002731 COVER, SPLIT/FIT BASKET 10 2
18 99002729 SPLIT/FIT BASKET 10 1
19 99002962 PAN RACK ASSEMBLY 17 1
- 99002905 CAP, RACK (DARK GRAY) 10 1
19 99002728 PAN RACK ASSEMBLY 10 1
20 99002780 WHEEL ASSEMBLY (LWR) 10 8
18
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
