DOOR
No. Part No. Description
Section:
Series Qty
1 99002771 PANEL, DECO (W/DAMPER-STNLS) 10 1
2 99002673 VENT HOUSING ASSEMBLY 10 1
3 N 99002604 CROSSBRACE, HINGE 13 1
3 N 99002604 CROSSBRACE, HINGE 10 2
4 99002929 BRACKET, HINGE (LT) 16 1
- 99001075 SCREW Note: SCREW, BRACKET 10 4
4 W10124350 NOT REQUIRED PART OR SEE NOTE Note: ***SEE NOTE*** (IF YOU NEED THE LEFT OR
RIGHTHINGE BRACKET FOR MODELS PRIORTO SERIES 16 ORDER 12002134)
10 1
4 99002930 BRACKET, HINGE (RT) 16 1
5 Y99002587 INSULATION, DOOR 10 1
6 903233 FOAM STRIP, INSULATION 10 1
7 99002589 SEAL, DOOR (BTM) 10 2
- 99002756 PUSHNUT, STAINLESS 10 2
8 99002970 DOOR, INNER (W/DAMPER) 17 1
- Y912620 SCREW Note: SCREW, DOOR 10 11
8 99002776 DOOR, INNER (W/DAMPER) 10 1
9 99002613 BRACKET, DISPENSER MOUNTING 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, BRACKET 10 6
10 99002270 SEAL, BASE 10 1
11 99002611 RINSE AID/DETERGENT DISPENSER 10 1
12 99002614 KNOB, RINSE AID (W/O-RING) 10 1
13 99002186 SEAL, DOOR VENT 10 1
14 99002590 BEZEL, DOOR VENT 10 1
- Y912620 SCREW Note: SCREW, REINFORCEMENT 10 3
15 99002586 REINFORCEMENT, INNER DOOR 10 1
5
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
