RACK ASSEMBLY (UPR)
No. Part No. Description
Section:
Series Qty
- 99002905 CAP, RACK (DARK GRAY) 10 1
1 99003019 RACK ASSEMBLY (UPR) 23 1
1 99002742 RACK ASSEMBLY (UPR) 10 1
2 99002712 VARILOCK (REAR) 10 1
3 99002714 CUP, VARILOCK 10 1
4 99002715 SPRING, VARILOCK 10 1
5 99002713 SUPPORT, VARILOCK 10 1
6 99002711 VARILOCK (FRT) 10 1
- 99002623 STOP, RACK (GRAY) 10 4
7 99002621 TRACK, RACK 10 2
- Y912798 WASHER, TUB WHEEL 10 8
- 99002343 SHAFT, TUB WHEEL 10 8
8 99002622 WHEEL, TUB 10 8
9 99002620 BASKET, AUXILLARY (BLUE) 10 1
10 99002624 ARM, WASH (UPR) 10 1
11 99002669 CLIP, UPR WASH MANIFOLD (FRT) 10 1
12 99002670 CLIP, UPR WASH MANIFOLD (BACK) 10 1
13 99002679 WASH MANIFOLD ASSY (UPR) 10 1
14 99002710 LATCH, FOLD AWAY TINE 10 1
15 99002708 TINE, FOLD AWAY (LT) 10 1
16 99002707 TINE, FOLD AWAY (RT) 10 1
17 99002709 PIVOT, FOLD AWAY TINE 10 2
18 99002696 CLIP, CUP (BLUE) 10 3
19 99002671 SHELF, CUP (UPR) 10 2
20 99002781 WHEEL ASSEMBLY (UPR) 10 4
7
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
