Maytag MDBH950AWS - Dishwasher Motor Connectivity; Motor Wire Harness Details

Motor Connectivity
!
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect power to dishwasher before servicing,
unless testing requires power.
16023222 6 May 2004
©2004 Maytag Services
Blue (Co mmon)
Yellow
(Main)
Green
(Ground)
Red
(Start)
1/3HP
120V/60hz, 3.2 amps, 3250 RPM
Wire harness
Connection plug
