56 PROGRAMMING MANUAL 516532 B PUBLICATION DATE 1 JUN 2007.DOC
HELP CODE H66 : WRONG VOLTAGE RANGE SELECTION
Help Code H66 occurs when the wrong Voltage Range has been selected in the Configuration menu.
Depending on the machine type and the inverter type, certain Voltage ranges are not allowed.
DIAGNOSE(ERR43):
1. Check the Machine Identification plate at the
back of the machine.
Select the same Voltage range in the
Configuration menu as on the Identification
plate of your washing machine.
Menu Item : Supply Voltage
HELP CODE H67 : WRONG INVERTER MODEL TYPE
Help Code H67 occurs when the wrong Inverter Model Type has been detected by the MCG AC software.
Before loading the parameters from the Wash Computer to the Mitsubishi inverter, the inverter type is
checked first.
DIAGNOSE(ERR44):
1. Check if you have selected the correct machine
type.
Select the correct machine type in the
Configuration menu.
Menu Item C:Machine Type
2. Check the Machine Identification plate at the
back of the machine.
Select the same Voltage range in the
Configuration menu as on the Identification
plate of your washing machine.
Menu Item C:Supply Voltage
HELP CODES H71, H74, H75, H76, H88 : CARD READER MESSAGES
These Help Codes are related with a disturbed communication process between Card Reader and MCG AC
Wash Computer.
These Help Codes are for informative purposes only and don't need technical intervention except if the problem
should be persistent.
ERROR CODE E35: WRONG SOFTWARE VERSION
When a total new software that isn’t downward compatible with previous software versions is loaded, then
the software will detect that the old and new software´s are not compatible.
You have to reconfigure the Graphic Control Wash Computer. See Chapter 4.
ATTENTION
!!!
ALL THE CUSTOM SETTINGS WILL BE ERASED IN THE GRAPHIC CONTROL WASH COMPUTER BY
LOADING THE FACTORY SETTINGS.
After reinitialization of the Graphic Control Wash Computer, fault 35 can only be erased by switching the
power Off/On.
!
