Maytag MRT711BZDH User Manual

6
Refrigerator Doors
Depending on the width of your doorway, you may need to
remove the doors to move the refrigerator into your home. Also,
the door hinges are factory-installed on the right-hand side. If you
want the door to open from the other direction, you must reverse
the door swing.
IMPORTANT:
■ Before you begin, turn the refrigerator control OFF, unplug
refrigerator or disconnect power. Remove food and any
adjustable door or utility bins from doors.
■ If you choose to reverse the door swing, a Reversibility Kit,
which includes a new brand badge and hole plugs, is
available.
Tools Needed: ⁵⁄₁₆" hex-head socket wrench, #2 Phillips
screwdriver, flat-blade screwdriver, ⁵⁄₁₆" open-end wrench, flat 2"
putty knife.
Remove Doors and Hinges
⁵⁄₁₆ " Hex-Head Hinge Screw
1. Unplug refrigerator or disconnect power.
2. Using a hex-head socket wrench, remove the three ⁵⁄₁₆"
hex-head hinge screws from the top hinge and lift up to
remove the hinge.
NOTE: Provide additional support for the doors while the
hinges are being moved. Do not depend on the door magnets
to hold the doors in place while you are working.
3. Lift the freezer door off of the center hinge and set it aside.
4. Remove the washer from the top of the center hinge pin.
5. Using a hex-head socket wrench, remove the three screws
from the center hinge and remove the hinge. Set aside.
6. Lift the refrigerator door off of the bottom hinge and set it
aside.
7. Open refrigerator door and remove base grille from the bottom
front of the refrigerator.
8. Using a hex-head socket wrench, remove the two ⁵⁄₁₆"
hex-head hinge screws attaching the bottom hinge to the
cabinet and remove the hinge from the bottom of the
refrigerator door.
A. ⁵⁄₁₆ " Hex-head hinge screws
B. Top hinge
C. Hinge pin
D. Spacer
A. Washer
A
B
C
D
A
A. Center hinge
B.
⁵⁄₁₆ " Hex-head hinge screws
A. Bottom hinge
A
B
A

Maytag MRT711BZDH Specifications

General

Type	built-in
Style	compact
Color	white
Number of Doors	2
Total Capacity	21.2 cubic feet
Refrigerator Capacity	21.2 cubic feet
Freezer Capacity	6.12 cubic feet
Humidity Controlled Crispers	yes
Defrost System	automatic
Number of Refrigerator Shelves	3
Interior Light	led
Dispenser	none
Ice Maker	yes
Water Filter	no
Smart Home	no
Annual Energy Consumption	443 kilowatt hours
Voltage	115 volts
Current	20 amperes

Weight and Dimensions

Depth	34.4 inches
Height	66.1 inches
Width	32.8 inches
Net Weight	0.1 pounds
