Maytag MRT711BZDH User Manual

7
Reverse Doors (optional)
See complete graphics later in these instructions.
Reverse Center Hinge
1. Remove the three dome caps and screws from the handle
side and use them to fill the holes created when the hinge
screws were removed.
2. Using the three ⁵⁄₁₆" hex-head hinge screws removed in
Step 1, insert two screws halfway into the holes, leaving
space to insert the center hinge.
3. Slide the center hinge, from the right, onto the screws, insert
the third screw, and then tighten all screws completely.
NOTE: Make sure the washers are in place on both the top
and bottom pins of the center hinge.
Reverse Freezer Door
1. Remove the three cabinet hole plugs from the top of the
cabinet and place them in the hinge holes on the opposite
side.
2. Remove the two screws from the bottom of the freezer door
handle.
3. Using the ¹⁄₈" hex key, loosen the setscrew attaching the top of
the handle. Then, pull the handle away from the door.
4. Using the plastic tool (provided), remove the brand badge
from the freezer door by prying up the right-hand side and
slowly peeling the badge away from the door, revealing the
hole to mount the door handle. Replace it with the badge
provided in the Reversibility Kit located inside the crisper. For
proper placement, see the Brand Badge Placement template
(the last page of this manual).
NOTES:
■ To avoid scratching the finish, do not use a sharp or
metallic object to pry the brand badge from the door.
■ Rub a small amount of liquid dish soap over any adhesive
residue with your fingers. Rinse the door with warm water
and dry with a soft cloth.
5. Remove the shoulder screw and its washer from the left-hand
side of the door and fasten it into the hole that was behind the
brand badge.
6. Remove the door stop from the bottom of the freezer door.
A. Dome cap washers
B.
⁵⁄₁₆ " Hex-head hinge screws
C. Dome caps
A.
⁵⁄₁₆ " Hex-head hinge screws
B. Washers
Door Hinge
Hole Plug
Cabinet Hinge
Hole Plug
Dome Cap
Dome Cap
Washer
Setscrew
Shoulder
Screw
Shoulder
Screw Washer
Door Stop
Screw
Flat-Head
Handle
Screw
Door Handle
Hole Plug
A
B
C
A
A
B
A. Cabinet hole plugs
A. Shoulder screw
B. Setscrew
C. Flat-head handle screws
A. Door stop screw
B. Door stop
A
B
A
C
B
A

Maytag MRT711BZDH Specifications

General

Type	built-in
Style	compact
Color	white
Number of Doors	2
Total Capacity	21.2 cubic feet
Refrigerator Capacity	21.2 cubic feet
Freezer Capacity	6.12 cubic feet
Humidity Controlled Crispers	yes
Defrost System	automatic
Number of Refrigerator Shelves	3
Interior Light	led
Dispenser	none
Ice Maker	yes
Water Filter	no
Smart Home	no
Annual Energy Consumption	443 kilowatt hours
Voltage	115 volts
Current	20 amperes

Weight and Dimensions

Depth	34.4 inches
Height	66.1 inches
Width	32.8 inches
Net Weight	0.1 pounds
