Maytronics CLASSIC 8+ - Dismantle and Clean the Impeller

13
CLASSIC 8+ / TOP 8 | User Instructions
1
2
9.1.5
9.1.6
WARNING
WARNING
Do not force the filters into place.
Unplug the power supply before cleaning.
Dismantle and Clean the Impeller
Octagonal
end
fitting
Grooved
end
fitting
1. Dismantle the impeller cover.
2. Clean around the impeller housing.
3. Reassemble.
(Warning: Use a Phillips screwdriver only,
not an electric screwdriver).
Reassemble the filter elements: Insert the locating tabs at the bottom of the filter element into
their grooves on the base frame. Clean the filter basket with a hose.
9.1.4
Locating tab
Locating tab groove
“S” clip
