4. Remove the bulb by pushing it in
slightly and turning it
counterclockwise.
5. Install the ne w bulb in the reverse order
of the removal procedure.
Parking lights/Front side-marker lights
1. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the left, and turn off engine.
If you are changing the left bulb, turn
the steering wheel to the right, and turn
off engine.
2. Make sure the headlight switch is off.
3. Pull the center of each plastic retainer
and remo ve the retainers.
Removal
Installation
4. Turn the screw counterclockwise and
remove it, and then partially peel back
the mudguard.
5. Turn the socket and bulb assembly
counterclockwise and remove it.
6. Disconnect the bulb from the socket.
7. Install the ne w bulb in the reverse order
of the removal procedure.
8-36
Maintenance and Care
Owner Maintenance
