Spare Tire and Tool Storage
Spare tire and tools are stored in the locations illustrated in the diagram.
Spare tire
Jack
Wing bolt
Jack lever
Lug wrench
Spare tire
Jack
Wing bolt
Jack lever
Lug wrench
Tiedown eyelet
(Mexico)
(Except Mexico)
Tiedown eyelet
Tiedown eyelet
In Case of an Emergency
Flat Tire
7-3
