Mazda 6 2011 - Instrument Cluster and Indicators; Meters and Gauges

Meters and Gauges
Speedometer ............................ .......................................................................... page 5-39
Odometer, Trip Meter, Outside Temperature Display and Selector ................... page 5-39
Tachometer ........................................................................................................ page 5-41
Engine Coolant Temperature Gauge .................................................................. page 5-42
Fuel Gauge ........................................................................................................ page 5-42
Dashboard Illumination ................... .................................................................. page 5-43
NOTE
(Black-out meter)
When the ignition is switched ON, the dashboard gauges illuminate.
5-38
Driving Your Mazda
Instrument Cluster and Indicators
