Engine Coolant Temperature Gauge
The engine coolant temperature gauge
shows the temperature of the engine
coolant.
If the needle is near H, it indicates
overheating.
CAUTION
Driving with an overheated engine
can cause serious engine damage
(page 7-12).
qFuel Gauge
The fuel gauge shows approximately how
much fuel is remaining in the tank when
the igni tion is switched ON.
We recommend keeping the tank over 1/4
full. When the low fuel warning light
illuminates or when the needle is near E,
refuel as soon as possible.
Low fuel
warning light
Full
Approx. 1/4 Full
NOTE
l
After refueling, it may require some time for
the needle to stabilize. In addition, the
needle may deviate while driving on a slope
or curve since the fuel moves in the tank.
l
The direction of the arrow ( ) next to the
low fuel warning light indicates that the
fuel-filler lid is on the left side of the
vehicle.
5-42
Driving Your Mazda
Instrument Cluster and Indicators
