6. Install the new bulb in the reverse order
of removal.
Side turn signal lights
í
, High-mount
brake light, Ground illumination
lights
í
Due to the complexity and difficulty of
the procedure, the bulbs must be replaced
by an Authorized Mazda Dealer.
Brake lights/Taillights (Rear side
marker lights)
LED type
Due to the complexity and difficulty of
the procedure, the LED bulbs must be
replaced by an Authorized Mazda Dealer.
NOTE
LED bulb replacement is not possible because
it is built into the unit. Replace the unit.
Bulb type
1. Pull the center section of the plastic
retainer and remove the retainers and
partially open the trunk side trim.
Removal
Installation
2. Turn the socket and bulb assembly
counterclockwise and remove it.
3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverse order
of removal.
NOTE
To replace the bulb, contact an Authorized
Mazda Dealer.
Rear turn signal lights
1. Pull the center section of the plastic
retainer and remove the retainers and
partially open the trunk side trim.
Removal
Installation
2. Turn the socket and bulb assembly
counterclockwise and remove it.
8-44
Maintenance and Care
í
Some models.
Owner Maintenance
Mazda6_8BG7-EC-10H_Edition1 Page444
Monday, August 2 2010 1:29 PM
Form No.8BG7-EC-10H
