3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverse order
of removal.
NOTE
To replace the bulb, contact an Authorized
Mazda Dealer.
Reverse lights
1. Pull the center section of the plastic
retainer and remove the retainers, then
partially peel back the trunk rear trim.
Removal
Installation
2. Turn the socket and bulb assembly
counterclockwise and remove it.
3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverse order
of removal.
License plate lights
1. Pull the center section of the plastic
retainer and remove the retainers, then
partially peel back the trunk rear trim.
Removal
Installation
2. Turn the socket and bulb assembly
counterclockwise and remove it.
Maintenance and Care
Owner Maintenance
8-45
Mazda6_8BG7-EC-10H_Edition1 Page445
Monday, August 2 2010 1:29 PM
Form No.8BG7-EC-10H
