3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverse order
of removal.
qReplacing Interior Light Bulbs
Overhead light/Map lights (Front),
Overhead light (Rear), Courtesy lights,
Vanity mirror lights
1. Wrap a small flathead screwdriver with
a soft cloth to prevent damage to the
lens and remove the lens by carefully
prying on the edge of the lens with the
flathead screwdriver.
2. Disconnect the bulb by pulling it out.
Overhead light/Map lights (Front)
Overhead light (Rear)
Courtesy lights
Vanity mirror lights
3. Install the new bulb in the reverse order
of removal.
8-46
Maintenance and Care
Owner Maintenance
