Obstruction Detection Indication
The position of a sensor which has detected an obstruction is indicated. The gauge
illuminates in different areas depending on the distance to an obstruction detected by the
sensor.
As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the
vehicle illuminates.
With 360° view monitorWithout 360° view monitor
Left front
corner sensor
Right front
corner sensor
Rear sensor Rear sensor
Left rear
corner sensor
Left front
corner sensor
Left rear
corner sensor
Right rear
corner sensor
Right front
corner sensor
Right rear
corner sensor
Front sensor Front sensor
NOTE
The detection indicator can switch between display and non-display.
Refer to Personalisation Features on page 9-9.
System problem notification
If a problem occurs, the driver is notified of the problem by the following indications.
Detection Indicator
Solution
Without 360° view monitor With 360° view monitor
Disconnec-
tion
The system may have a malfunc-
tion. Have the vehicle inspected at
an expert repairer, we recommend
an Authorised Mazda Repairer as
soon as possible.
When Driving
Parking Sensor System
4-187
