Mazda CX-8 - Flat Tyre

Spare Tyre and Tool Storage
Spare tyre and tools are stored in the locations illustrated in the diagram.
Wheel brace
Spare tyre hold-down bolt
Spare tyre hold-down bolt
Towing eyelet
Toolbag
Jack lever
Jack
Spare tyre
Toolbag
Wheel brace
Towing eyelet
Jack lever
Jack
Spare tyre
With sub-woofer
Without sub-woofer
Screwdriver
Wrench
Screwdriver
Wrench
If Trouble Arises
Flat Tyre
7-3
