Jack
To remove the jack
1. Open the luggage board, and remove
it.
Luggage board
2. Remove the cargo sub-compartment
cover on the right side.
Cargo sub-compartment cover
3. Lift the luggage mat.
Luggage mat
4. Remove the cargo sub-compartment.
Cargo sub-compartment
5. Turn the wing bolt and jack screw
anticlockwise.
Wing bolt
Jack screw
To secure the jack
1. Insert the wing bolt into the jack with
the jack screw pointing back and turn
the wing bolt clockwise to temporarily
tighten it.
If Trouble Arises
Flat Tyre
