9. Align the blade component projection
with the wiper arm notch.
Notch
Projection
10. Slide the blade component and install
it to the wiper arm.
11. Slowly lower the wiper arm onto the
windscreen.
▼
Replacing Rear Window Wiper
Blade
When the wiper no longer cleans well, the
blade is probably worn or cracked.
Replace it.
CAUTION
To prevent damage to the wiper arm and
other components, do not move the wiper
by hand.
1. Raise the wiper arm and rotate the
wiper blade to the right until it
unlocks, then remove the blade.
CAUTION
To prevent damage to the rear window,
do not let the wiper arm fall on it.
2. Pull down the blade rubber and slide it
out of the blade holder.
3. Remove the metal stiffeners from the
blade rubber and install them in the
new blade.
Maintenance and Care
Owner Maintenance
6-24
