4. Pull the centre of each plastic retainer
using a flathead screwdriver and
remove the retainers, and then partially
peel back the mudguard.
Removal
Installation
5. Turn the socket and bulb assembly
anticlockwise and remove it.
6. Disconnect the bulb from the socket.
7. Install the new bulb in the reverse
order of the removal procedure.
Rear direction indicator lights
1. Make sure the ignition is switched off,
and the direction indicator switch is
off.
2. Wrap a small flathead screwdriver with
a soft cloth to prevent damage to the
cover, and then remove the cover with
the flathead screwdriver.
3. Turn the screws anticlockwise and
remove them.
4. Pull the unit rearward to remove it.
5. Turn the socket and bulb assembly
anticlockwise and remove it.
Maintenance and Care
Owner Maintenance
6-37
