Speed symbol Maximum permissible speed
Y Up to 300 km/h (186 mph)
ZR Over 240 km/h (149 mph)
Tyre and inflation pressure
NOTE
The tyres have been optimally matched with the chassis of your vehicle.
When replacing tyres, Mazda recommends that you replace tyres of the same type originally
fitted to your vehicle. For details, contact an expert repairer, we recommend an Authorised
Mazda Repairer.
Check the tyre pressure label for tyre size and inflation pressure.
Refer to Tyre Pressure Label on page 9-2.
Refer to Tyre Inflation Pressure on page 6-31.
Standard tyre
Tyre size
Inflation pressure
Up to 3 persons ―Full load
225/55R19 99V
Front 250 kPa (2.5 bar, 36 psi) 260 kPa (2.6 bar, 38 psi)
Rear 250 kPa (2.5 bar, 36 psi) 290 kPa (2.9 bar, 42 psi)
1 person's weight: About 75 kg
Temporary spare tyre
Tyre size Inflation pressure
T155/80R17 100M 420 kPa (4.2 bar, 60 psi)
Wheel nut tightening torque
When installing a tyre, tighten the wheel nut to the following torque.
108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)
▼
Fuses
Refer to Fuses on page 6-42.
▼
Brakes
If you require information regarding the wear limit specification for the brake disc plates
and the measurement method, please contact an expert repairer, we recommend an
Authorised Mazda Repairer. The information is made freely available.
Specifications
Specifications
9-8
