6 – 51
Maintenance and Care
Owner Maintenance
7. Temporarily install the light unit with
the socket pulled out of the top of the
light unit.
Socket pull-out range
CAUTION
¾
The wiring harness may be damaged
when temporarily installing the light
unit. When performing the procedure,
observe the following points.
¾
Pull out the socket from within the
socket pull-out range shown in the
 gure.
¾
Do not push the light unit into the
vehicle with force.
¾
When temporarily installing the light
unit, cover the rear bumper light unit
installation surface with a soft cloth.
The rear bumper may be scratched or
damaged if the light unit contacts it.
8. Disconnect the bulb from the socket.
9. Install the new bulb in the reverse order
of the removal procedure.
