9 – 6
Speci¿ cations
Speci¿ cations
Weights
U.S.A. and Canada
Item
Weight
2WD AWD
GVWR (Gross Vehicle Weight Rating) 2,568 kg (5,661 lbs) 2,638 kg (5,816 lbs)
GAWR (Gross Axle Weight Rating)
Front 1,217 kg (2,683 lbs) 1,241 kg (2,736 lbs)
Rear 1,386 kg (3,056 lbs) 1,433 kg (3,159 lbs)
Mexico
Item
Weight
2WD AWD
GVW (Gross Vehicle Weight)
Total 2,490 kg (5,489 lbs) 2,555 kg (5,633 lbs)
Front 1,175 kg (2,590 lbs) 1,195 kg (2,634 lbs)
Rear 1,315 kg (2,899 lbs) 1,360 kg (2,998 lbs)
GAW (Permissible axle load)
Front 1,210 kg (2,668 lbs) 1,215 kg (2,679 lbs)
Rear 1,365 kg (3,009 lbs) 1,415 kg (3,120 lbs)
Air Conditioner
The type of refrigerant used is indicated on a label attached to the inside of the engine
compartment. Check the label before recharging the refrigerant. Refer to Climate Control
System on page 5-2 .
Item Classi¿ cation
Refrigerant Type HFC134a (R-134a)
